| • Hardware |
| Comm. Controller |
MU860 (16C550C compatible) |
| Bus |
32-bit Universal PCI |
| Connector |
DB62 female |
| • Serial Interface |
| Number of Ports |
8 |
| Serial Standards |
RS-232 |
| Max. No. of Boards per PC |
4 |
| • Serial Line Protection |
| ESD Protection |
15 KV on the board |
| Optical Isolation |
500 V with connection box Opt8F (must be purchased separately) |
| • Performance |
| Baudrate |
50 bps to 921.6 Kbps |
| • Serial Communication Parameters |
| Data Bits |
5, 6, 7, 8 |
| Stop Bits |
1, 1.5, 2 |
| Parity |
None, Even, Odd, Space, Mark |
| Flow Control |
RTS/CTS, XON/XOFF |
| I/O Address |
Assigned by BIOS |
| IRQ |
Assigned by BIOS |
| • Serial Signals |
| RS-232 |
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| • Driver Support |
| Operating Systems |
Windows 9X/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64, Windows CE 5.0/6.0, Windows XP Embedded, DOS, Linux 2.4, Linux 2.6 x86/x64, FreeBSD 4/5, QNX 6, SCO Open Server 5/6, UnixWare 7, Solaris 10 x86/x64 |
| Note |
Please refer to Moxa's website for the latest driver support information. |
| • Physical Characteristics |
| Dimensions |
82 x 120 mm (3.22 x 4.72 in) |
| • Environmental Limits |
| Operating Temperature |
Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F) |
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity |
5 to 95% (non-condensing) |
| • Standards and Certifications |
| EMC |
CE, FCC |
| EMI |
EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class B |
| EMS |
EN 55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 (DIPS) |
| Green Product |
RoHS, CRoHS, WEEE |
| • MTBF (mean time between failures) |
| Time |
280,854 hrs |
| Database |
Telcordia (Bellcore), GB |
| • Power Requirements |
| Power Consumption |
180 mA @ +5 V |
| • Warranty |
| Warranty Period |
5 years |
