HMQ-5501 55-Inch 4K SDI Display For Live Video Monitoring Features: 4K UHD 3840 x 2160 resolution Anti-Burn-inTM technology prevents image ghosting Image Enhancer: 3D Comb Filter / Deinterlace / Noise Reduction Versatile connectivity: SDI, HDMI, DVI, VGA, Composite (BNC) Supports multiple SDI formats: 3G/HD/SD-SDI Embedded audio in SDI up to 8 channels of 48kHz BNC passive loop-through output port RS232/LAN Control - provides compatibility with control systems Black-level adjustment for presenting more details in dark images Selectable gamma curves optimise different kinds of images CCTV picture mode for maximum image detail in low light footage Optional blue or black screen when no input signal is detected Lockable control keys to prevent tampering in public environments commercial-grade panel for high reliability and long product lifetime 24/7 Operation with a rugged metal housing design Specifications: Panel Panel Type IPS Panel Size 54.6" Max. Resolution UHD 3840 x 2160 Pixel Pitch 0.315 mm Brightness 350 cd/m² Contrast Ratio 1200:1 Viewing Angle (H/V) 178°/178° Display Colour 1.07B Colour Gamut NTSC 68% Response Time 5 ms Surface Treatment Anti-Glare Treatment (Haze 1%) 3H Hard Coating Frequency Frequency (H) 15KHz~135KHz Frequency (V) 24Hz ~ 86 Hz Signal Input SDI BNC x 1 HDMI 2.0 x 1 DVI 24-Pin DVI-D VGA 15-Pin D-Sub x 1 Composite BNC x 1 Signal Output SDI BNC x 1 Composite BNC x 1 External Control RS232 In 9-Pin D-Sub LAN RJ45 x 1 Other Connectivity USB 2.0 x 1 (Service Port) Audio Audio In Stereo Audio Jack (3.5 mm) Audio Out S/PDIF Stereo Audio Jack (3.5 mm) Internal Speakers 5 W x 2 Power Power Supply Internal Power Requirements AC 100-240V 50/60 Hz On Mode 99W (On) Standby Mode < 0.5W Off Mode < 0.3W Operating Conditions Temperature 0°C-40°C (32°F-104°F) Humidity 20%-85% (non-condensing) Storage Conditions Temperature -10°C-60°C (-4°F-140°F) Humidity 10%-95% (non-condensing) Mounting VESA FPMPMI Yes (400 x 400 mm) Dimensions Product w/o Base (W x H x D) 1243.2 x 714.0 x 69.6 mm (48.9" x 28.1" x 2.7") Packaging (W x H x D) 1364.0 x 824.0 x 154.0 mm (53.7" x 32.4" x 6.1") Weight Product w/o Base 15.0 kg (33.1 lb) Packaging 18.8 kg (41.5 lb) Regulation Approval Certifications & Compliance CE LVD WEEE RoHS REACH EAC UKCA Accessories Supplied Batteries HDMI Cable Power Cord Quick Start Guide Remote Control Optional Accessories Video Wall Mount VWM-01 VWM-02 Ceiling Mount (Landscape only) CMP-01 + LMK-01 Wall Mount (Landscape only) LMA-01 LMA-02 LMK-01 LMK-03 Floor Mount (Landscape only) FMC-02 FMC-03 + LMK-04 FMC-04 + LMK-04 FMC-05B FMC-06 FMS-01 FMS-02 FWL-01B Desk mount (Landscape only) DTS-01
